This is a fresh containerized design - Atlas ABP array of asphalt blending plant from India. Significant improvements in the old design helps it be ideal and maintenance free - for road technicians wanting reliable and durability. Better knowledge of this product and track record of proving excellent service help to customers in India and abroad makes Atlas a common title. Asphalt batching plant (containerized design) will come in three capabilities 80 tph, 120 tph and 160 tph. Capabilities above 160 tph are also available as they are tailor made.
The standard configuration includes:
Cold feeder containers
Primary scalping display
Charging you conveyor
Drying out drum with burner unit
Elevator to simply take hot aggregates towards tower product
Tower product includes vibrating screens, hot containers and mixing unit. Tower device additionally houses evaluating bins for filler and bitumen.
Bitumen tanks with hot oil system for heating bitumen and jacketing the mixing unit.
Filler hopper / silo with screw conveyor /elevator.
Bag filter product with pre-separator
Control panel system for hot-mix plant.
The main focus of Atlas once we developed this design was to improvise regarding the current device which makes sure that the new plant is reduced on operating expense, reduced on maintenance and it is affordable your can purchase. We didn't desire to increase the expense element while enhancing the design. The brand new machine is simple to use because it includes PLC panel. The units are modular helping to make construction and start up very fast. The tower product comes on skid installed dishes to make certain that minimal foundation is required within site and regular levelling regarding the land will suffice.
The cost of this containerized design asphalt group plant is much less than exactly what your competition is offering while this gear is much simpler and low cost when we compare the upkeep element. It is possible to count on it for high quality hot mix asphalt and at the same time expect it to execute constantly for many years ahead.
Containerized design facilitates reducing the transport price considerably.
Built on a durable and strong framework - suited to harsh working conditions.
The tower unit is on skid mounted dishes. Other units can also be provided on skid dishes on demand of client.
This asphalt group mix plant from Asia can easily be thought to be the much better styles regarding low-to-zero maintenance and reduced working expenses.
High efficient and low noise multi gasoline burner product is what you want.
Thermally insulated drying out drum with selection for rubbing drive and sequence drive offered.
Modular products are made for simple transportation and fast installation of the gear.
Modular design also allows effortless loading into containers and simple unloading at customer’s website.
Total seven pneumatic cylinders found in the machine each of same dimensions so free administration is not hard – we have been asphalt batching plant producers whose focus is on customer care.
Bitumen weighing system is significantly easier compared to old design which makes it even more energy saving.
Maintenance of this cylinders mounted on hot bins is very simple now.
Mixing device includes planetary gear boxes on each shaft for better performance and torque consumption.
Minimal municipal work needed must be performed at website.
New case filter design is sold with 3 rotors for cleansing effectiveness.
We do use standard materials inside production.
The control board of asphalt batch combine plant obtainable is perfect for easier procedure.
Screen sizes can be individualized depending on your necessity.
Ease of access for fast upkeep allowing you to achieve maximum productivity.
This equipment normally available with endeavor kind damp dust collector as opposed to bag filter unit for air pollution control - for countries in which pollution control norms tend to be less stringent.
The cost of the free components could be the cheapest in the market.
Very user-friendly PLC control board provides substitute for store a lot of different hotmix recipes with possibility to improve the dishes usually.
Aspects of the asphalt plant tend to be:
Hot aggregate container elevator: completely enclosed product - the container elevator for hot aggregates make the aggregates from drying drum below into the vibrating display over the tower unit. It's supplied with wear dishes, drives (electrical and mechanical) and wiring.
Mineral filler feeding system: the conventional setup comes with filler hopper and screw conveyors for feeding the filler product to the filler hopper.
Because of the asphalt batch combine plant India, a recommended filler elevator can certainly be supplied. It can help in transferring the minerals through the filler storage bins to your filler weigh hopper situated regarding the tower device. The amount signal on the dust storage container controls the circulation of filler from filler elevator. This unit is fully enclosed bucket type elevator system.
Vibrating display: The vibrating screen is four decked and it is for separation of various types of aggregates. Screen sizes could be custom-made depending on certain requirements of the consumer. The scalping display screen of Atlas asphalt group plants obtainable is huge providing a large enough screening area so aggregates can move rapidly and uninterrupted movement is aggregates is accomplished. It is inclined and vibrating kind that will be rested on spring absorbers.
There is room enough near the screening system which makes maintenance effortless. The display screen replacement is also effortless making the module among simplest to keep up. Screen design allows for quick elimination of the oversized aggregates.
